Technical Data and features
Total length: 70½"-82" (179-210 cm), w/o front wheel 61" (155 cm)
Total width: 32" (83 cm)
Total height: 38"-42" (98.5-106.5 cm)
Seat height: 23"-26" (58.5-66.5 cm)
Bottom bracket height: 12½" (32 cm)
Wheelbase: 50"-63" (129-160 cm)
Frame: 6061 aluminum
Fork: aluminum
Max. load: 309 lb (140 kg)
Wheels: 20"
Brakes: Promax DSK300 mech. disc brakes, forged aluminum brake levers with locking mechanism
Tires: Kenda 58-406mm with reflective sidewalls and puncture protection
Gear system: 24-speed; Shimano Altus Mix, development 1.43 m to 7.36 m (equivalent to 7 km/h to 40 km/h)
Crankset: Samox, 155 mm, 50/39/30 T
Lighting system: none
Weight: 47.4 lb (21.5 kg)
Color: RAL 9005 Jet Black gloss, RAL 3002 Carmine Red gloss / powder-coated
